01
Mark the height.
Measure your preferred mounting height and mark it. A standard height is around 20–28 inches from the floor.
Figura support
Install the Roto.
The current Roto uses a four-screw mounting plate and a click-on body. Follow these four steps, keeping the plate’s shorter side up.
- 4 steps
- From mark to click
- 4 screws
- Through the plate
- Short side up
- When leveling
Before you start
Gather your tools.
- Pencil, tape measure, and level
- Drill or Phillips-head screwdriver
- 3/16-inch drill bit for concrete or tile wall inserts
Installation
Four steps. One click.
02
Level the plate.
Hold the mounting plate against the wall at your mark with the shorter side up, then level it.
Concrete or tile: Drill the holes with an appropriate bit for the wall material.
03
Secure the plate.
Drive the four provided screws through the countersunk holes of the mounting plate and into the wall.
Concrete or tile: Tap an included insert into each hole until it is flush with the surface. Set the plate back over the inserts, then drive in the screws.
04
Slide until it clicks.
Slide the Roto onto the plate until you hear it click. It may take a little extra force.
Protect the arms. Apply pressure only to the base while sliding the Roto onto the plate.
Printable reference
Prefer the guide beside you?
Download the current four-step Roto installation guide before you start. It includes the mounting orientation and concrete or tile notes in one printable file.
Download the PDF
